Gigabyte GA-H110M-D3H R2 (rev. 1.0) [11/39] Displayport

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out (Green)

The line out jack. Use this audio jack for a headphone or 2-channel speaker. This jack can be used to

connectfrontspeakersina4/5.1/7.1-channelaudioconguration.

Mic In (Pink)

The Mic in jack.

Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomoduleandenablethe

multi-channel audio feature through the audio driver. Please visit GIGABYTE's website for more

software information.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• When removing the cable, pull it straight out from the connector. Do not rock it side to side to prevent

an electrical short inside the cable connector.

Serial Port

Use the serial port to connect devices such as a mouse, modem or other peripherals.

DisplayPort

DisplayPort delivers high quality digital imaging and audio, supporting bi-directional audio transmission.

DisplayPort can support both DPCP and HDCP content protection mechanisms. You can use this port to

connect your DisplayPort-supported monitor. The maximum supported resolution is 4096x2304@60 Hz,

but the actual resolutions supported are dependent on the monitor being used.

USB 3.1 Gen 1 Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

HDMI Port

The HDMI port is HDCP compliant and supports Dolby TrueHD and DTS HD

Master Audio formats. It also supports up to 192KHz/16bit 8-channel LPCM

audio output. You can use this port to connect your HDMI-supported monitor. The maximum supported

resolution is 4096x2160@24 Hz, but the actual resolutions supported are dependent on the monitor being

used.

Activity LED

Connection/

Speed LED

LAN Port

Connection/Speed LED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

Activity LED:

State Description

Blinking Data transmission or receiving is occurring

Off No data transmission or receiving is occurring

• Tosetupadual-displayconguration,youmustinstallmotherboarddriversintheoperating

systemrst.

• After installing the HDMI/DisplayPort device, make sure to set the default sound playback

device to HDMI/DisplayPort. (The item name may differ depending on your operating system.)

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

- 11 -
