- 4 -
GA-H110M-D3H R2 Motherboard Layout
Box Contents
5 GA-H110M-D3H R2 motherboard 5 Two SATA cables
5 Motherboard driver disk 5 I/O Shield
5 User's Manual
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
KB_MS_USB
LGA1151
ATX
BAT
ATX_12V_2X4
Intel
®
H110
CLR_CMOS
PCIEX16
F_USB30_1
CODEC
GA-H110M-D3H R2
CPU_FAN
PCI1
PCI2
PCIe to PCI Bridge
SYS_FAN
F_AUDIO
AUDIO
R_USB30_1
M_BIOS
USB_LAN
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1
LPT
F_USB2
F_PANEL
SPDIF_O
VGA
SATA3
DDR4_2
DDR4_4
DDR4_3
DDR4_1
DVI
COM
DP
COMB
B_BIOS
3 1
2 0
PCIEX4
HDMI
