- 11 -
Hardware Installation
Storage Interface Chipset:
- 4xSATA6Gb/sconnectors(sSATA30~3),supportingIDEandAHCImodes
only
(An operating system installed on the SATA3 0~5 ports cannot be used on the
sSATA30~3ports.)
USB Chipset:
- 4xUSB3.0/2.0ports(availablethroughtheinternalUSBheaders)
- 10 x USB 2.0/1.1 ports (6 ports on the back panel, 4 ports available through
theinternalUSBheaders)
Chipset+Renesas
®
USB 3.0 Hub:
- 4 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 Socket 3 connector
1 x SATA Express connector
10 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1 x Clear CMOS jumper
1 x power button
1 x reset button
1 x Clear CMOS button
1 x audio gain control switch
2 x BIOS switches
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 3.0/2.0 ports
6 x USB 2.0/1.1 ports
1xRJ-45port
1 x optical S/PDIF Out connector
5xaudiojacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
LineOut,MicIn)
2 x Wi-Fi antenna connector holes
I/O Controller iTE
®
I/O Controller Chip
