![Gigabyte GA-X99M-Gaming 5 (rev. 1.1) [10/124] 2 product specifications](/img/pdf.png)
Gigabyte GA-X99M-Gaming 5 (rev. 1.1) [10/124] 2 product specifications
![Gigabyte GA-X99M-Gaming 5 (rev. 1.1) [10/124] 2 product specifications](/views2/1232999/page10/bga.png)
- 10 -
Hardware Installation
1-2 ProductSpecications
CPU Support for Intel
®
Core
™
i7 processors in the LGA2011-3 package
(GotoGIGABYTE'swebsiteforthelatestCPUsupportlist.)
L3 cache varies with CPU
Chipset Intel
®
X99 Express Chipset
Memory 4xDDR4DIMMsocketssupportingupto64GBofsystemmemory
* DuetoaWindows32-bitoperatingsystemlimitation,whenmorethan4GBofphysical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
4 channel memory architecture
SupportforDDR42133/1866/1600/1333MHzmemorymodules
Support for non-ECC memory modules
SupportforExtremeMemoryProle(XMP)memorymodules
SupportforRDIMM1Rx8memorymodules(operateinnon-ECCmode)
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC1150 codec
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN RivetNetworksKiller
™
E2400 LANchip(10/100/1000Mbit)
Expansion Slots 2xPCIExpressx16slots,runningatx16(PCIE_1/PCIE_2)
* Foroptimumperformance,ifonlyonePCIExpressgraphicscardistobeinstalled,
be sure to install it in the PCIE_1 slot; if you are installing two PCI Express graphics
cards, it is recommended that you install them in the PCIE_1 and PCIE_2 slots.
1xPCIExpressx16slot,runningatx8(PCIE_3)
* Whenani7-5820KCPUisinstalled,thePCIE_2slotoperatesatuptox8modeand
the PCIE_3 operates at up to x4 mode.
(AllPCIExpressx16slotsconformtoPCIExpress3.0standard.)
1 x PCI Express x1 slot
(ThePCIExpressx1slotconformstoPCIExpress2.0standard.)
1xM.2Socket1connectorforthewirelesscommunicationmodule(M2_WIFI)
Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and 2-Way NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFireX
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA & PCIe x2/x1
SSDsupport)(M2_10G)
- 1 x SATA Express connector
- 6xSATA6Gb/sconnectors(SATA30~5)
- SupportforRAID0,RAID1,RAID5,andRAID10
* OnlyAHCImodeissupportedwhenanM.2PCIeSSDoraSATAExpressdeviceis
installed.
(M2_10G, SATA Express, and SATA3 4/5 connectors can only be used one at a
time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is
installedintheM2_10Gconnector.)
