Gigabyte GA-X99-Ultra Gaming-EK (rev. 1.0) [6/128] Box contents

- 6 -

Box Contents

GA-X99-Ultra Gaming motherboard

Motherboard driver disk

User's Manual

Quick Installation Guide

Six SATA cables

I/O Shield

One 2-Way SLI bridge connector

One 3-Way SLI bridge connector (GC-3SLI-X99-1)

Two Velcro Cable Ties

One G Connector

One 1 to 3 power cable (2x4-pin ATX 12V)

OneRGBLEDstripextensioncable

Optional Items



2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)



eSATAbracket(PartNo.12CF1-3SATPW-4*R)



3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)

The box contents above are for reference only and the actual items shall depend on the product package you

obtain. The box contents are subject to change without notice.
