Gigabyte GA-Z97X-Gaming G1 (rev. 1.0) [6/136] Box contents

- 6 -

Box Contents

5 GA-Z97X-Gaming G1 motherboard

5 Motherboard driver disk

5 User's Manual

5 Quick Installation Guide

5 Six SATA cables

5 I/O Shield

5 One 2-Way SLI bridge connector

5 One 3-Way SLI bridge connector

5 One 4-Way SLI bridge connector

5 One 2-Way CrossFire bridge connector

Optional Items

 2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)

 eSATAbracket(PartNo.12CF1-3SATPW-4*R)

 3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)

 HDMI-to-DVIadapter(PartNo.12CT2-HDMI01-1*R)

The box contents above are for reference only and the actual items shall depend on the product package you

obtain. The box contents are subject to change without notice.
