& Setup Administrator Password
Allowsyoutocongureanadministratorpassword.Press<Enter>onthisitem,typethepassword,and
thenpress<Enter>.Youwillberequestedtoconrmthepassword.Typethepasswordagainandpress
<Enter>. You must enter the administrator password (or user password) at system startup and when entering
BIOS Setup. Differing from the user password, the administrator password allows you to make changes to
all BIOS settings.
& User Password
Allowsyoutocongureauserpassword.Press<Enter>onthisitem,typethepassword,andthenpress
<Enter>.Youwillberequestedtoconrmthepassword.Typethepasswordagainandpress<Enter>.
You must enter the administrator password (or user password) at system startup and when entering BIOS
Setup. However, the user password only allows you to make changes to certain BIOS settings but not all.
To cancel the password, press <Enter> on the password item and when requested for the password, enter
thecorrectonerst.Whenpromptedforanewpassword,press<Enter>withoutenteringanypassword.
Press<Enter>againwhenpromptedtoconrm.
NOTE:BeforesettingtheUserPassword,besuretosettheAdministratorPasswordrst.
& HDDSecurityConguration
Displaysalistofconnectedharddrivesandallowsyoutosetapasswordforaspecicharddrive.This
item appears only when a hard drive is installed.
` Secure Boot
& System Mode
Displays the current system mode.
& Vendor Keys
Displays the vendor keys.
& Secure Boot
Displays the current secure boot state. (Default: Disabled)
& Secure Boot Customization
Allowsyoutocongurethesecurebootmode.(Default:Custom)
2-4 Security
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc.
Password Description
If ONLY the Administrator's password is set,
then this only limits access to Setup and is
only asked for when entering Setup.
If ONLY the Administrator's password is set,
is a power on password and must be entered to
boot or enter Setup. In Setup the User will
have Administrator rights.
The password length must be
in the following range:
Minimum length 3
Maximum length 20
Setup Administrator Password
User Password
` Secure Boot
gf: Select Screen
hi: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Main
Advanced
Boot Save & ExitSecurity
- 30 -
