Gigabyte B450M H [37/42] 1 configuringaraidset

Chapter 3 Appendix

3-1 ConguringaRAIDSet

Before you begin, please prepare the following items:

• At least two SATA hard drives or SSDs. (To ensure optimal performance, it is recommended that you use

two hard drives with identical model and capacity).

(Note)

• Windows setup disc.

• Motherboard driver disc.

• A USB thumb drive.

ConguringtheOnboardSATAController

A. Installing SATA hard drive(s) in your computer

Install the hard drives/SSDs in the SATA/M.2 connectors on the motherboard. Then connect the power connectors

from your power supply to the hard drives.

B.ConguringSATAcontrollermodeinBIOSSetup

MakesuretoconguretheSATAcontrollermodecorrectlyinsystemBIOSSetup.

Steps:

1. Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).

Under Chipset, ensure APU SATA Port Enable and Chipset SATA Port Enable are enabled. set SATA

Mode to RAID. Then save the settings and restart your computer. (If you want to use NVMe PCIe SSDs to

congureRAID,makesuretosetNVMe RAID mode to Enabled.)

2. IfyouwanttocongureUEFIRAID,followthestepsin"C-1."ToenterthelegacyRAIDROM,savethe

settingsandexitBIOSSetup.Referto"C-2"formoreinformation.

The BIOS Setup menus described in this section may differ from the exact settings for your motherboard.

The actual BIOS Setup menu options you will see shall depend on the motherboard you have and

the BIOS version.

RAID Levels

RAID 0 RAID 1 RAID 10

Minimum Number of

Hard Drives

≥2 2 4

Array Capacity Number of hard drives *

Sizeofthesmallestdrive

Sizeofthesmallestdrive (Number of hard drives/2) *

Sizeofthesmallestdrive

Fault Tolerance No Yes Yes

C-1.UEFIRAIDConguration

Steps:

1. In BIOS Setup, go to BIOS and set CSM Support to Disabled. Save the changes and exit BIOS Setup.

2. After the system reboot, enter BIOS Setup again. Then enter the Peripherals\RAIDXpert2Conguration

Utility sub-menu.

3. On the RAIDXpert2CongurationUtility screen, press <Enter> on Array Management to enter the Create

Array screen. Then, select a RAID level.RAIDlevelssupportedincludeRAID0(Stripe),RAID1(Mirror),

andRAID10(theselectionsavailabledependonthenumberoftheharddrivesbeinginstalled).Next,press

<Enter> on Select Physical Disks to enter the Select Physical Disks screen.

(Note) AnM.2PCIeSSDcannotbeusedtosetupaRAIDseteitherwithanM.2SATASSDoraSATAhard

drive.

- 37 -
