Gigabyte B450M DS3H WIFI [6/44] 2 product specifications
![Gigabyte B450M DS3H WIFI [6/44] 2 product specifications](/views2/1669284/page6/bg6.png)
1-2 ProductSpecications
CPU AM4 Socket:
- AMD 3rd Generation Ryzen
™
processors
- AMD 2nd Generation Ryzen
™
processors
- AMD 1st Generation Ryzen
™
processors
- AMD 2nd Generation Ryzen
™
with Radeon
™
Vega Graphics processors
- AMD 1st Generation Ryzen
™
with Radeon
™
Vega Graphics processors
- AMD Athlon
™
with Radeon
™
Vega Graphics processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD B450
Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for DDR4 2933/2667/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
(Note)
* Support for HDMI 2.0 version and HDCP 2.2.
(Note)
Maximum shared memory of 16 GB
Audio Realtek
®
ALC887 codec
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you need to open the audio software and select
Device advanced settings > Playback Device to change the default setting rst.
Please visit GIGABYTE's website for details on conguring the audio software.
Support for S/PDIF Out
LAN Realtek
®
GbE LAN chip (1000/100 Mbit)
Wireless
Communication
Module
Intel
®
Wi-Fi AC 3168
- Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Mbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
1 x PCI Express x16 slot, running at x1 (PCIEX1_2)
1 x PCI Express x1 slot
(The PCIEX1_1 and PCIEX1_2 slots conform to PCI Express 2.0 standard.)
(Note) Actual support may vary by CPU.
- 6 -
