Technical details - TZB Range up to 700 kW
Cooling only EWAD-TZSSB/SLB
160 190 240 270 300 360 380 450 495 570 610 660 700
Cooling capacity Nom. kW
169 200 235 268 306 351 394 455 499 569 612 660 700
Power input
Cooling Nom. kW
56.5 69.9 83.0 89.9 108 119 139 163 174 198 217 239 249
EER
2.99 2.87 2.83 2.99 2.82 2.95 2.83 2.78 2.86 2.88 2.81 2.76 2.81
ESEER
4.55 4.61 4.41 4.59 4.57 4.65 4.61 4.62 4.71 4.83 4.80 4.81 4.89
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
2,283 3,183 4,083 4,983 5,883 6,783
Weight (SSB)
Unit kg
2,066 2,091 2,149 2,375 2,422 2,771 4,044 4,060 4,317 4,603 4,780 4,804 5,074
Operation weight kg
2,086 2,117 2,187 2,401 2,460 2,821 4,202 4,224 4,475 4,761 5,050 5,059 5,329
Weight (SLB) Unit kg
2,081 2,106 2,164 2,390 2,437 2,786 4,074 4,090 4,347 4,633 4,810 4,834 5,104
Operation weight kg
2,101 2,132 2,202 2,416 2,475 2,836 4,232 4,254 4,505 4,791 5,080 5,089 5,359
Water heat exchanger Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
8.1 9.6 11.2 12.9 14.6 16.8 18.9 21.8 23.9 27.3 29.3 31.6 33.5
Water pressure drop
Cooling Nom. kPa
25.0 19.3 15.4 32.6 25.2 25.9 32.4 44.0 55.7 38.8 32.3 36.0
Water volume l
20.2 26.1 37.3 26.1 37.3 49.5 158 164 158 270 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
4 6 8 10 12 14
Air ow rate Cooling Nom. l/s
15,109 22,664 30,219 37,774 45,328 52,883
Sound power level (SSB) Cooling Nom. dBA
96 97 98 99 100 101 102 105
Sound pressure level (SSB)
Cooling Nom. dBA
77 78 79 80 82 84
Sound power level (SLB) Cooling Nom. dBA
90 90.5 91.5 92.5 93.5 94 94.5 95.5 96.5 98.5
Sound pressure level (SLB)
Cooling Nom. dBA
71 72 73 74 75 76 77
Operation range Air side Cooling
Min.~Max.
°CDB
-18~47
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
27 29 33 38 41 52 29 29.5 34 37.5 38.5 41.5 45
TCO₂eq
39 41 47 54 59 74 41 42 49 54 55.0 59 64
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
Cooling only EWAD-TZXSB/XLB
190 220 240 290 320 360 420 450 540 570 610 660 680
Cooling capacity Nom. kW
180 211 239 276 313 360 417 472 529 563 599 639 678
Power input
Cooling Nom. kW
52.1 63.2 72.5 83.9 100 109 132 144 163 181 191 202 219
EER
3.46 3.34 3.30 3.13 3.30 3.16 3.26 3.24 3.11 3.13 3.16 3.09
ESEER
5.28 5.20 5.15 5.25 5.32 5.39 5.31 5.26 5.31 5.35 5.29 5.36 5.31
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
3,183 4,083 4,983 5,883 6,783 7,683
Weight (XSB)
Unit kg
2,362 2,409 2,421 2,770 4,292 4,602 4,800 5,072 5,425
Operation weight kg
2,388 2,447 2,459 2,820 4,450 4,760 5,055 5,327 5,680
Weight (XLB) Unit kg
2,377 2,424 2,436 2,785 4,322 4,632 4,830 5,102 5,455
Operation weight kg
2,403 2,462 2,474 2,835 4,480 4,790 5,085 5,357 5,710
Water heat exchanger Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
8.6 10.1 11.5 13.2 15.0 17.3 20.0 22.6 25.3 27.0 28.7 30.6 32.4
Water pressure drop
Cooling Nom. kPa
16.4 13.2 16.2 17.1 21.0 34.3 31.2 39.7 36.7 41.1 27.1 30.5 33.3
Water volume l
26.1 37.3 49.5 158 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
6 8 10 12 14 16
Air ow rate Nom. l/s
22,664 30,219 37,774 45,328 52,883 60,438
Speed rpm
700
Sound power level (XSB)
Cooling Nom. dBA
96 97 96 97 98 99 100 101
Sound pressure level (XSB)
Cooling Nom. dBA
77 78 79 80
Sound power level (XLB) Cooling Nom. dBA
91 91.5 91 91.5 92.5 93.5 94 94.5 95 95.5
Sound pressure level (XLB)
Cooling Nom. dBA
72 72 73 74 73 74
Operation range Air side Cooling
Min.~Max.
°CDB
-18~50
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
36 39 40 51 32 37 40 44.5 48
TCO₂eq
51 56 57 73 46 53 57 64 69
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
Cooling only EWAD-TZSRB
160 190 240 270 300 360 380 450 495 570 610 660 700
Cooling capacity Nom. kW
169 200 235 268 306 351 394 454 499 568 610 659 699
Power input
Cooling Nom. kW
56.5 69.9 83 89.9 108 119 140 164 175 199 218 240 250
EER
2.99 2.87 2.83 2.99 2.82 2.95 2.81 2.76 2.85 2.86 2.80 2.74 2.80
ESEER
4.55 4.61 4.41 4.59 4.57 4.65 4.59 4.60 4.69 4.81 4.82 4.78 4.88
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
2,283 3,183 4,083 4,983 5,883 6,783
Weight
Unit kg
2,166 2,191 2,249 2,475 2,522 2,871 4,244 4,260 4,517 4,803 4,980 5,004 5,274
Operation weight kg
2,186 2,217 2,287 2,501 2,560 2,921 4,402 4,424 4,675 4,961 5,250 5,259 5,529
Water heat exchanger
Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
8.1 9.6 11.2 12.9 14.6 16.8 18.8 21.7 23.9 27.2 29.2 31.5 33.5
Water pressure drop
Cooling Nom. kPa
25.0 19.3 15.4 32.6 25.2 25.9 25.8 32.2 43.9 55.5 38.6 32.2 35.9
Water volume l
20.2 26.1 37.3 26.1 37.3 49.5 158 164 158 270 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
4 6 8 10 12 14
Air ow rate Cooling Nom. l/s
15,109 22,664 30,219 29,650 36,920 44,475 51,745
Speed rpm
700
Sound power level
Cooling Nom. dBA
86 87 88 90 91 92 94
Sound pressure level
Cooling Nom. dBA
67 68 69 70 70 70 71 73
Operation range
Air side Cooling
Min.~Max.
°CDB
-18~47
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
27 29 33 38 41 52 29 29.5 34 37.5 38.5 41.5 45
TCO₂eq
39 41 47 54 59 74 41 42 49 54 55 59 64
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
