Daikin EWAD700TZ-SSB2 [7/8] Technical details tzb range up to 700 kw
![Daikin EWAD540TZ-XSB2 [7/8] Technical details tzb range up to 700 kw](/views2/1670363/page7/bg7.png)
7
Technical details - TZB Range up to 700 kW
Cooling only EWAD-TZXRB
190 220 240 290 320 360 420 450 540 570 610 660 680
Cooling capacity Nom. kW
180 211 239 276 313 360 417 472 528 562 598 638 677
Power input
Cooling Nom. kW
52.1 63.2 72.5 83.9 100 109 132 145 164 181 192 203 220
Capacity control
Method
Stepless
Minimum capacity %
34 29 34 29 25 17 16 17 16 15 14 13
EER
3.46 3.34 3.30 3.13 3.29 3.16 3.24 3.22 3.09 3.11 3.15 3.07
ESEER
5.28 5.20 5.15 5.25 5.32 5.37 5.31 5.24 5.29 5.33 5.32 5.34 5.29
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
3,183 4,083 4,983 5,883 6,783 7,683
Weight
Unit kg
2,462 2,509 2,521 2,870 4,492 4,802 5,000 5,272 5,625
Operation weight kg
2,488 2,547 2,559 2,920 4,650 4,960 5,255 5,527 5,880
Water heat exchanger
Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
8.6 10.1 11.5 13.2 15.0 17.2 20.0 22.6 25.3 26.9 28.6 30.5 32.4
Water pressure drop
Cooling Nom. kPa
16.4 13.2 16.2 17.1 21.0 34.2 31.2 39.7 36.6 41.0 27.1 30.4 33.2
Water volume l
26.1 37.3 49.5 158 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
6 8 10 12 14 16
Air ow rate Nom. l/s
22,664 30,219 36,920 37,774 44,475 51,745 59,299
Speed rpm
700
Sound power level
Cooling Nom. dBA
88 89 90 91 92
Sound pressure level
Cooling Nom. dBA
68 69 70 71
Operation range
Air side Cooling
Min.~Max.
°CDB
-18~50
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
36 39 40 51 32 37 40.0 44.5 48
TCO₂eq
51 56 57 73 46 53 57 64 69
Piping connections
Evaporator water inlet/outlet (OD)
3“ 4“ 5“ 6”
Unit
Starting current Max A
77 89 101 118 137 184 211 237 256 275 300 321 342
Running current Cooling Nom. A
110 113 186 192 226 231 373.0 385 393 391 389 396
Max A
130 149 166 198 225 256 292 333 358 385 417 450 478
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
Cooling only EWAD-TZPSB/PLB
190 220 240 290 300 350 420 495
Cooling capacity Nom. kW
183 216 244 281 323 379 435 501
Power input
Cooling Nom. kW
50.5 60.7 68.7 83.4 95.9 104 123 139
EER
3.64 3.56 3.55 3.38 3.37 3.62 3.53 3.60
ESEER
5.70 5.66 5.58 5.59 5.55 5.67 5.69 5.71
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
4,083 4,983 5,883 6,783
Weight (PSB)
Unit kg
2,758 2,769 2,770 3,020 4,735 5,069 5,077
Operation weight kg
2,808 2,819 2,820 3,070 4,990 5,324 5,332
Weight (PLB) Unit kg
2,773 2,784 2,785 3,035 4,765 5,099 5,107
Operation weight kg
2,823 2,834 2,835 3,085 5,020 5,354 5,362
Water heat exchanger Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
8.8 10.3 11.7 13.5 15.5 18.1 20.8 24.0
Water pressure drop
Cooling Nom. kPa
10.6 11.0 13.4 17.1 21.5 20.4 26.3 33.3
Water volume l
49.5 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
8 10 12 14 16
Air ow rate Cooling Nom. l/s
29,610 37,013 44,415 51,818 59,220
Speed rpm
700
Sound power level (PSB)
Cooling Nom. dBA
97 98 99 100
Sound pressure level (PSB)
Cooling Nom. dBA
77 78 77 78
Sound power level (PLB) Cooling Nom. dBA
91 91.5 91 91.5 92 93.5 94
Sound pressure level (PLB) Cooling Nom. dBA
71 72 71 72 73 72 73
Operation range Air side Cooling
Min.~Max.
°CDB
-18~52
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
49 50 51 58 38.5 43 47
TCO₂eq
70 72 73 83 55 61 67
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
Cooling only EWAD-TZPRB
190 220 240 290 300 350 420 495
Cooling capacity Nom. kW
187 218 246 279 317 382 435 505
Power input
Cooling Nom. kW
50.5 60.7 68.7 83.4 95.9 105 123 139
EER
3.71 3.59 3.35 3.31 3.64 3.52 3.62
ESEER
5.70 5.66 5.42 5.33 5.39 5.50 5.41 5.63
Dimensions Unit Height mm
2,483
Width mm
2,258
Depth mm
4,083 4,983 5,883 6,783
Weight
Unit kg
2,858 2,869 2,870 3,120 4,935 5,269 5,277
Operation weight kg
2,908 2,919 2,920 3,170 5,190 5,524 5,532
Water heat exchanger
Type
Plate heat exchanger Single pass shell & tube
Water ow rate Cooling Nom. l/s
9.0 10.4 11.8 13.3 15.2 18.3 20.8 24.2
Water pressure drop
Cooling Nom. kPa
10.6 11.0 13.4 17.1 21.5 20.4 26.2 33.2
Water volume l
49.5 255
Air heat exchanger
Type
Microchannel
Compressor
Type
Inverter driven single screw compressor
Quantity
1 2
Fan
Type
Direct propeller
Quantity
8 10 12 14 16
Air ow rate Cooling Nom. l/s
29,610 37,013 43,369 50,423 57,826
Speed rpm
700
Sound power level
Cooling Nom. dBA
87 88 87 88 89 90
Sound pressure level
Cooling Nom. dBA
67 68 67 68 69
Operation range
Air side Cooling
Min.~Max.
°CDB
-18~52
Water side Cooling
Min.~Max.
°CDB
-8~18
Refrigerant
Type / GWP
R-134a / 1,430
Circuits Quantity
1 2
Refrigerant charge Per circuit kg
49 50 51 58 38.5 43 47
TCO₂eq
70 72 73 83 55 61 67
Power supply Phase/Frequency/Voltage Hz/V
3~/50/400
The full range includes units up to 1,100 kW
