■ Features

File Name:PSC-160-SPEC 2014-07-01

Bauar

Sicherheit

egel gema

tgepruft

www.

ID 2000000000

tuv.com

wac g

•Security system

•Emergency lighting system

•Alarm system

•UPS system

•Central monitoring system

•Access systems

■ Applications

■ Description

160W Single Output with Battery Charger(UPS Function)

PSC-160 series

•Universal AC input / Full range

•Built-in active PFC function

•6"x3" compact PCB size

•Models with L-Bracket and cover available

(PSC-160x-C, x=A,B)

•Protections: Short circuit / Overload / Over voltage

•Battery low protection / Battery reverse polarity

protection by fuse

•Relay contact signal output for AC OK and

Battery Low

•Cooling by free air convection

•100% full load burn-in test

•2 years warranty

-C

Blank : PCB type

-C : Enclosed type

{

Output voltage

Output wattage

Series name

-APSC - 160

PSC-160 series is a 160W AC/DC security power supply, allowing the universal input range between

90VAC and 264VAC and incorporating the built-in PFC function. In addition to the primary output, there

is a charger output, with the smaller rated current, that provides the backup power supply application the

security access systems require.

PSC-160 delivers an efficiency up to 90%; it can operate with air convection under -20 through 70 . ℃℃

This series is designed with thorough alarm features, including AC OK and battery low signaling;

moreover, the relay contact is provided to facilitate users' system designs. PSC-160 is available in the

PCB type or the enclosed type with L-Bracket and cover.

■ Model Encoding
