Bat+
+V
-V
Bat-
Load
A : 12V
B : 24V
Battery
+
+
-
-
Suggested Application
CN3 Pin2(Pin4)
External voltage source (V)
and resistor (R)
(The max. Sink is 1A and 30V)
1.Backup connection for AC interruption
2.Alarm signal for AC OK and Battery Low
(1) Please refer to the Fig1.1 for suggested connection.
(1) Alarm signal is sent out through " AC OK " & " Battery Low " pins.(relay contact type)
(2) An external voltage source is required for this function. The maximum applied voltage is 30V and the maximum sink current is 1A.
(3) Table2.1 explains the alarm function built in the power supply
AC OK (Battery low)
CN3 Pin1(Pin3)
Function
Output of Alarm
voltage 30V max.)
voltage 30V max.)
Low or short
Low or short
High or open(External applied
High or open(External applied
Description
The signal is "Low" when the power supply
The signal is "Low" when the voltage of
The signal is "High" when the voltage of
The signal turns to be "High" when the power
turns on
battery is under A:11V, B:22V
battery is above A:11V, B:22V
supply turns OFF
AC OK
Battery
Low
The power supply charges the battery and provides energy to the load at the same time when the AC main is OK.
The battery starts to supply power to the load when the AC mains fails.
Fig 1.1 Suggested system connection
Table 2.1 Explanation of Alarm Signal
R
V
160W Single Output with Battery Charger(UPS Function)
PSC-160 series
File Name:PSC-160-SPEC 2014-07-01
Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
90 10095 120115 160140 200180 240220 264
LOAD (%)
90
100
80
70
60
50
40
Output Derating
AMBIENT TEMPERATURE ( )℃
LOAD (%)
-20
02010 30 40
20
40
50
80
60
100
6050
70
(HORIZONTAL)
(4) RL1 (AC OK)signal will go into hiccup mode when the overload protection is activating.
Fig 2.2 Internal circuit of AC OK (Battery Low)
CN2
1
2
CN3
1
2
3
4
SVR1
HS3
PCB only
45
1
CN1
FS1
3
2
AC FUSE
T 4.0A/250V
3
4
5
6
7
8
HS1
Enclosed tpye
