MEAN WELL RPD-60B [2/2] Series

MEAN WELL RPD-60B [2/2] Series
Mechanical Specification
File Name:RPD-60-SPEC 2014-12-13
Block Diagram
CIRCUIT
DETECTION
O.L.P.
EMI
FILTER
RECTIFIERS
&
FILTER FILTER
FILTER
&
&
RECTIFIERS
RECTIFIERS
+V1
V2
COM
I/P
FG
CONTROL
O.V.P.
Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
90 10095 120115 160140 200180 240220 264
LOAD (%)
90
100
80
70
60
50
40
Unit:mm
fosc : 100KHz
(HORIZONTAL)
65
Derating Curve
POWER
SWITCHING
AC Input Connector (CN1) : JST B3P-VH or equivalent
Pin No.
1
2
3
Assignment
AC/N
No Pin
AC/L
Mating Housing
JST VHR JST SVH-21T-P1.1
or equivalent or equivalent
Terminal
3
1
4
2
5
6
CN2
4- 3.3ψ
101.6
50.8
95.25
CN1
FS1
FS2
2
3
1
44.45
3.175
3.175
AC FUSE
T2.5/250V
AC FUSE
T2.5/250V
29
3 max.
HS1
HS2
HS1,HS2 can not be shorted
DC Output Connector (CN2) : JST B6P-VH or equivalent
Pin No.
1,2
3,4
5
6
Assignment
V1
V2
COM
NC
Mating Housing
JST VHR
or equivalent
Terminal
JST SVH-21T-P1.1
or equivalent
: Grounding required
AMBIENT TEMPERATURE ( )℃
LOAD (%)
-20 0 2010 30 40
20
40
80
60
100
6050
70
60W Dual Output Medical Type
RPD-60 series
