SPECIFICATION

RPD-65C

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

VOLTAGE ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

AC CURRENT (Typ.)

12V 5V

4.5A 1.2A

0 ~ 5.8A 0 ~ 1.5A

Rated load

60W

Rated output power for convection; 77.1W with 18CFM min. forced air

120mVp-p 50mVp-p

CH1:11.4 ~ 12.8V

±2.0%

±5.0%

±1.0% ±1.0%

800ms, 20ms at full load

20ms at full load

90 ~ 264VAC 127 ~370VDC

47 ~ 440Hz

1.5A/115VAC 0.9A/230VAC

COLD START 25A/115VAC 50A/230VAC

<1mA

CH1:13.8 ~ 16.2V

90 ~ 125W output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed.

-20 ~ +60℃ (Refer to "Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85 , 10 ~ 95% RH℃

± ℃ ℃0.04%/ (0 ~ 50 ) on CH1 output

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

288.1K hrs min. MIL-HDBK-217F (25 )℃

PCB:127*76*29mm (L*W*H) ; with optional CASE:130*85*37mm (L*W*H)

PCB:0.24Kg; 63pcs/16Kg/1.35CUFT ; with optional CASE:0.47Kg;32pcs/16Kg/0.64CUFT

File Name:RPD-65 -SPEC 2013-05-27

OVER VOLTAGE

SAFETY STANDARDS

Compliance to EN61000-3-2,-3EN55022 (CISPR22) Class B,

Compliance to EN55024, light industry level, criteria AEN61000-4-2,3,4,5,6,8,11,

■

 

R PD -65

se r ie s

ENVIRONMENT

SAFETY &

EMC

(Note 5)

PROTECTION

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

RIPPLE & NOISE (max.)

Note.2

VOLTAGE TOLERANCE

Note.3

                 

                       

           

                         

 

℃

                      

                 

   

‧

   

       

  

       

        

    

    

  

     

OUTPUT POWER (max.)

UL60950-1, TUV EN60950-1 approved

CH2 CH1 CH2CH1

7.5A 3.75APEAK LOAD

Note.4

OUTPUT NUMBER

81%79%

65W Dual Output Switching Power Supply

RPD-65D

24V 5V

2.25A 1.2A

0 ~ 2.9A 0 ~ 1.5A

Rated load

60W

50mVp-p150mVp-p

CH1:22.8 ~ 26.4 V

±5.0%

±2.0%

±1.0%±1.0%

CH1:27.6 ~ 32.4V

EMC IMMUNITY

EMC EMISSION
