MEAN WELL RPD-65C [2/3] Series
![MEAN WELL RPD-65D [2/3] Series](/views2/1672115/page2/bg2.png)
File Name :RPD-65-SPEC 2013-05-27
Case No. 946A Unit:mm
DC Output Connector (CN2 ) : Molex 5273-06 or equivalent
Pin No.
1,2
3,4
5
6
Assignment
V1
GND
V2
NC
Mating Housing
Molex 5195
or equivalent
Terminal
Molex 5194
or equivalent
AC Input Connector (CN1) : Molex 5273-03 or equivalent
Pin No.
1
2
3
Mating Housing
Molex 5195
Molex 5194
or equivalent
or equi valent
Terminal
Mechanical Specification
1
3
CN1
3
1
2
CN2
5
4
6
SVR1
2
5.6115.8
127
FS1
18CFM mi n.
FAM
(60W convection, 77W with FAN)
Optional L-Bracket:
No. 946A-D
Assignment
AC/L
No Pin
AC/N
Block Diagram
fosc : 65KHz
O.V.P.
CONTROL
COM
+V2
RECTIFIERS
&
FILTER
SWITCHING
POWER
FILTER
&
RECTIFIERS
O.L .P.
DETECTION
CIRCUIT
PWM
FILTER
&
RECTIFIERS
+V1
FG
I/P
FILTER
EMI
Opt ional cover:
No. 946A-T
65W Dual Output Switching Power Supply
R P D -65
se rie s
