Hotpoint-Ariston ECOT6L 1091 EU [2/72] Installation

Installation

! Keep this instruction manual in a safe place for future

reference. Should the appliance be sold, transferred or

moved, make sure the instruction manual accompanies

the washing machine to inform the new owner as to its

operation and features.

! Read these instructions carefully: they contain vital infor-

mation on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the washing

machine.

2. Check whether the

washing machine has

been damaged during

transport. If this is the

case, do not install it and

contact your retailer.

3. Remove the four

protective screws and

the rubber washer with

the respective spacer,

situated on the rear of the

appliance (see figure).

4. Seal the gaps using the

plastic plugs provided.

5. Keep all the parts: you will need them again if the wa-

shing machine needs to be moved to another location.

Warning: should the screws be re-used, make sure you fasten

the shorter ones at the top.

! Packaging materials are not children’s toys.

Levelling

Your machine may make a considerable amount of noise if

the two front feet have not been adjusted correctly.

1. Install the washing ma-

chine on a flat sturdy floor,

without resting it up against

walls, furniture cabinets or

other.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening

or loosening the adjustable

front feet (see figure); the

angle of inclination, measu-

red according to the worktop, must not exceed 2°.

Levelling your appliance correctly will provide it with sta-

bility and avoid any vibrations, noise and shifting during

operation. If it is placed on a fitted or loose carpet, adjust

the feet in such a way as to allow enough room for ventila-

tion beneath the washing machine.

Putting your appliance in place and moving it.

If your washing machine is

equipped with a special set

of retractable wheels you

can easy move it. To lower

the wheels and thus move

the appliance effortlessly, just

pull the lever, situated on the

left-hand side beneath the

base. Once the appliance is

in the required position, put

the lever back in place. The

washing machine is now

firmly in place (see figure)

Electric and water connections

Connecting the water inlet hose

1. Connect the supply pipe

by screwing it to a cold water

tab using a ¾ gas threaded

connection (see figure).

Before performing the con-

nection, allow the water to run

freely until it is perfectly clear.

2. Connect the other end of

the water inlet hose to the

washing machine, screwing

it onto the appliance’s cold

water inlet, situated on the

top right-hand side on the

rear of the appliance (see

figure).

3. Make sure there are no kinks or bends in the hose.

! The water pressure at the tap must be within the values

indicated in the Technical details table

(on the next page).

! If the water inlet hose is not long enough, contact a spe-

cialist store or an authorised serviceman.
