MEAN WELL MSP-1000-12 [110/112] Mounting accessories
![MEAN WELL MSP-1000-12 [110/112] Mounting accessories](/views2/1676800/page110/bg6e.png)
ITEM Order No. Case Model
MHS012
206, 207
215A
912, 915
916, 935
939, 940
977, 980
982, 986
987, 995
HDP-190, RSP-200/320,LRS-200/350
RSP-150
S-201, S-320,
S-350, SP-100,
SP-150, SP-200,SP-320,
SE-450/1000, MP450/650/1000,
SP-240, HRP-300/450/600,
RSP-2400/3000
MHS013
919
926
PSP-500, SP-750,
SE-600
MHS014
212
952
RSP-750
RSP-1000, SD-1000
MHS025
910 SP-500, PSP-600.....
MHS026
943 RSP-1500
MHS027
971
931
RS-15
RS-25
TBC is the cover for
terminal block
TBC-05
901
903
905
932
220
239A
240A
SD-50, S-60
S-40, NES-50, RS-75
S-25, SD-25, NES-35, RS-50
NES-25, RS-35
RSP-75
LRS-35/50
LRS-75
TBC-07
901
902
903
905
906
215A
227A
238A
241A
D/ID-60, NED/T-75, RD-85,
NES-100, RS-100, T-60
S-100F, RD-125, NES-150,
RS-150, SD-100,
NED/T-50, RD/RID-65, T-40
NED/T-35,RD-50
S-150, SC-150, SD-150
RSP-150
RSP-100
LRS-100
LRS-150, LRS-150F
TBC-08
901
906
AD-155, ADD/ADS-155
D/T/Q-120
TBC-09
207 RSP-200/320, LRS-200/350
2-F3x4 ISO
2-F3x4 ISO
2-F3x4 ISO
2-F3x4 ISO
107
Accessories
DIN Rail Accessories
Mounting Accessories
ITEM Order No. Case Model
DRL-01
238, 239, 240
903
905
931
932
971
LRS-35/50/75/100
S-40, D-30, T-30, .....
S-15, S-25, .....
RS-25, NES-15
RS-35, NES-25
RS-15
DRL-02
241
901
902
906
915
916
920
LRS-150/150F
S-50, S-60, D-60, .....
S-100, S-100F, SD-100, ....
S-150, SD-150, D-120, .....
SP-100, .....
SP-150, SP-200, .....
SP-75, .....
DRL-03A
980
987
SP-240, HRP
(
G
)
-300
DRP-01
238, 239, 241
901, 902
903, 906
931, 932, 946
LRS-35/50/100/150/150F
All models
DRP-01A
203
205
978
999
RSD-100 / 150 / 200 / 300
DRP-02
240
905 / 915
916 / 920
928
LRS-75
S-15, S-25, ... / SP-100, ...
SP-150, SP-200, .. / SP-75, ...
USP-225, .....
DRP-03
DRP-01
DRL-01~03
All models
DRP-04
203
205
978
999
RSD-100 / 150 / 200 / 300
