26 | 75
TECHNICAL SPECIFICATION
MODEL
EWYT235B-
XSA2
EWYT265B-
XSA2
EWYT310B-
XSA2
EWYT350B-
XSA2
COOLING PERFORMANCE
Capacity - Cooling
kW
229
250
288
328
Capacity control - Type
STEP
STEP
STEP
STEP
Capacity control - Minimum capacity
%
17
25
22
19
Unit power input - Cooling
kW
74.9
83.4
95.9
109
EER
3.06
3
3.06
3.05
SEER
4.4
4.13
4.57
4.67
IPLV
4.87
4.64
4.94
4.96
CASING
Colour *
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
1800
1800
2514
2514
Width
mm
1195
1195
2282
2282
Length
mm
6150
6150
4125
4125
WEIGHT
Unit Weight
kg
2300
2350
2830
3080
Operating Weight
kg
2335
2385
2865
3115
WATER HEAT EXCHANGER
Type *
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
Water Volume
l
35
35
35
35
Water temperature in
°C
12
12
12
12
Water temperature out
°C
7
7
7
7
Water flow rate
l/s
10.9
11.9
14
16
Water pressure drop
kPa
14.6
17.1
22.8
28.9
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT EXCHANGER
Type *
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
Drive *
Phase cut
Phase cut
On/Off
On/Off
Diameter
mm
450
450
800
800
Nominal air flow
l/s
24104
24104
29593
33820
Air Temperature
°C
35
35
35
35
Quantity
No.
16
16
7
8
Speed
rpm
1200
1200
700
700
Motor input
kW
6.7
6.7
6
6.9
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Oil charge
l
16.5
17.7
19.6
21.4
Quantity
No.
4
4
4
4
SOUND LEVEL**
Sound Power - Cooling
dB(A)
89.7
90.6
92.4
93.4
Sound Pressure level@1m distance
- Cooling
dB(A)
70.2
71.1
72.4
73.4
REFRIGERANT CIRCUIT
Refrigerant type
R32
R32
R32
R32
Refrigerant charge
kg
50
55
70
70
N. of circuits
No.
2
2
2
2
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
88.9
88.9
88.9
88.9
