INSTALLATIONS NOTES
71 | 75
SPECIFICATIONS
Legend;
a
Single Pump
l
Check valve
b
Two pumps- parallel
configuration
m
Plugged fitting
c
Twin pump
n
Flow switch fitting 1”
d
Valve
o
Flow switch fitting ½ ”
e
Check Valve
p
Automatic filling valve fitting
f
Safety Valve
q
Plugged fitting
g
Plugged fitting
r
Water filter
h
Air vent
TT
Temperature sensor
i
drain
TS
Temperature switch
j
Tank
PI
Pressure gauge
k
Electrical heater
FS
Flow switch
General The unit will be designed and manufactured in accordance with the following European directives:
•
Construction of pressure vessel 2014/68/EU
•
Machinery Directive 2006/42/EC
•
Low Voltage 2014/35/EU
•
Electromagnetic Compatibility 2014/30/EU
•
Electrical & Safety codes EN 60204–1 / EN 60335-2-40
•
Manufacturing Quality Standards UNI – UNI EN ISO 1400
The unit will be tested at full load in the factory (at the nominal working conditions and water temperatures).
The unit will be delivered to the job site completely assembled and charged with refrigerant and oil.
The installation of the unit must comply with the manufacturer’s instructions for rigging and handling equipment.
The unit will be able to start up and operate (as standard) at full load with:
- Outside air temperature from............... °C to............... °C
-
Water Side Heat Exchanger leaving fluid temperature between............... °C and............... °C
Refrigerant HFC R-32
Performance Unit shall supply the following performances:
•
Number of unit(s):............... unit(s)
•
Cooling capacity for single unit:............... kW
•
Power input for single unit in cooling mode:............... kW
•
Heat exchanger entering water temperature in cooling mode:............... °C
•
Heat exchanger leaving water temperature in cooling mode:............... °C
•
Heat exchanger water flow in cooling:............... l/s
•
Nominal outside working ambient temperature in cooling mode:............... °C
•
Minimum full load efficiency (EER): …………….. (kW/kW)
•
Minimum part load efficiency (SEER): …………….. (kW/kW)
•
Heating capacity for single unit:............... kW
•
Power input for single unit in heating mode:............... kW
•
Heat exchanger entering water temperature in heating mode:............... °C
•
Heat exchanger leaving water temperature in heating mode:............... °C
•
Heat exchanger water flow in heating:............... l/s
•
Nominal outside working ambient temperature in heating mode:............... °C
•
Minimum full load efficiency (COP): …………….. (kW/kW)
•
Minimum part load efficiency (SCOP): …………….. (kW/kW)
Operating voltage range should be 400V ±10%, 3ph, 50Hz (or 380V ±10%, 3ph, 60Hz), voltage unbalance
maximum 3%, without neutral conductor and shall only have one power connection point.
