Daikin EWYT235B-XSA2 [30/75] Technical specification
![Daikin EWYT235B-XSA2 [30/75] Technical specification](/views2/1677852/page30/bg1e.png)
30 | 75
TECHNICAL SPECIFICATION
MODEL
EWYT400B-
XLA2
EWYT440B-
XLA2
EWYT500B-
XLA2
EWYT560B-
XLA2
EWYT600B-
XLA2
EWYT630B-
XLA2
EWYT650B-
XLA2
COOLING PERFORMANCE
Capacity - Cooling
kW
370
406
467
519
560
597
610
Capacity control -
Type
Step
Step
Step
Step
Step
Step
Step
Capacity control -
Minimum capacity
%
17
25
22
19
18
17
17
Unit power input -
Cooling
kW
122
134
158
177
193
204
207
EER
3.02
3.01
2.95
2.93
2.9
2.92
2.95
SEER
4.54
4.57
4.72
4.71
4.70
4.69
4.4
IPLV
4.96
5
5.1
5.08
5.05
5.05
4.66
CASING
Colour *
IW
IW
IW
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
2514
2514
2514
2514
2514
2514
2514
Width
mm
2282
2282
2282
2282
2282
2282
2282
Length
mm
5025
5025
5925
5925
6825
6825
6825
WEIGHT
Unit Weight
kg
3810
3910
4366
4456
4920
5020
5020
Operating Weight
kg
3845
3972
4428
4526
4990
5090
5090
WATER HEAT EXCHANGER
Type *
PHE
PHE
PHE
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
0
0
0
Water Volume
l
35
62
62
70
70
70
70
Water temperature
in
°C
12
12
12
12
12
12
12
Water temperature
out
°C
7
7
7
7
7
7
7
Water flow rate
l/s
17.7
19.4
22.3
24.7
26.7
28.5
29.1
Water pressure drop
kPa
34.7
23.6
30.4
33.6
38.6
43.2
45
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT EXCHANGER
Type *
HFP
HFP
HFP
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
DPT
DPT
DPT
Drive *
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
Diameter
mm
800
800
800
800
800
800
800
Nominal air flow
l/s
43351
42276
52021
50730
60692
59186
78410
Air Temperature
°C
35
35
35
35
35
35
35
Quantity
No.
10
10
12
12
14
14
14
Speed
rpm
700
700
700
700
700
700
900
Motor input
kW
8.6
8.6
10.3
10.3
12.1
12.1
24.4
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge
l
23.3
25.2
29.6
34
35.9
37.8
37.8
Quantity
No.
4
4
5
6
6
6
6
SOUND LEVEL**
Sound Power -
Cooling
dB(A)
88
88.2
88.9
89
89.6
89.7
95.3
Sound Pressure
level@1m distance -
Cooling
dB(A)
67.6
67.8
68.1
68.2
68.5
68.6
74.2
REFRIGERANT CIRCUIT
Refrigerant type
R32
R32
R32
R32
R32
R32
R32
Refrigerant charge
kg
85
100
114.5
129
143.5
158
158
N. of circuits
No.
2
2
2
2
2
2
2
PIPING CONNECTIONS
Evaporator water
inlet/outlet
mm
88.9
88.9
88.9
88.9
88.9
88.9
88.9
