MEAN WELL RCP-1000-48-C Data Sheet онлайн
SPECIFICATION - Single Unit
RCP-1000-12 RCP-1000-24
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
Note.5
FREQUENCY RANGE
EFFICIENCY (Typ.)
INPUT
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
AC CURRENT (Typ.)
12V 24V
60A 40A
0 ~ 60A 0 ~ 40A
720W 960W
150mVp-p
11.6 ~ 12.4V
200mVp-p
23.2 ~ 24.8V
±1.0% ±1.0%
±0.5%
±0.5%
1000ms, 60ms/230VAC at full load
16ms/230VAC at full load
90 ~ 264VAC 127 ~ 370VDC
47 ~ 63Hz
81%
COLD START 50A
8.5A/115VAC 4.5A/230VAC 10.5A/115VAC 5.5A/230VAC 11A/115VAC 5.5A/230VAC
<1.1mA / 230VAC
RCP-1000-48
48V
21A
0 ~ 21A
1008W
300mVp-p
46.3 ~ 49.7V
±1.0%
±0.5% ±0.5%
±0.5% ±0.5%
‧
Universal AC input / Full range
‧
Built-in 5V/0.3A auxiliary power
‧
Built-in active PFC function, PF>0.96
‧
Protections: Short circuit / Overload / Over voltage / Over temperature
‧
Forced air cooling by built-in DC fan with fan speed control
‧
Low profile:1U height
‧
Active current sharing up to 3000W (3 units)in 19" rack, 3 racks max.
can be operated in parallel (up to 8 units)
(
Note.7)
‧
Remote control for single unit
‧
Built-in remote sense function
‧
Output voltage trimming function
‧
Hot-swap operation
‧
Optional I C serial data bus
2
‧
AC OK & DC OK signal
‧
Internal ORing diode
‧
3 years warranty
RIPPLE & NOISE (max.)
Note.2
VOLTAGE TOLERANCE
Note.3
87% 89%
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER TEMPERATURE
OVERLOAD
OVER VOLTAGE
105 ~ 125% rated output power
13.2 ~ 16.2V
Protection type : Shut down o/p voltage, re-power on to recover
Shut down o/p voltage, recovers automatically after temperature goes down
26.4 ~ 32.4V 52.8 ~ 64.8V
PROTECTION
■SELECTION GUIDE
Single Unit: RCP-1000-
Rack: RCP-1U
Whole System: RCP-3K1U - -
I
I 12 C
-12 C
C: With I C Interface
C: With I C Interface
: Without I C Interface
: Without I C Interface
Output Voltage
Output Voltage
I: AC Inlet(IEC320-C14)
I: AC Inlet(IEC320-C14)
T: Terminal Block
T: Terminal Block
-
-
2
2
2
2
1000 ~ 3000W Front End Power System
■
Features :
RCP
seri e s
Fi le Name:RCP series-SPEC 2015-02-11
Содержание
- Series 1
- 3000w front end power system 2
- Series 2
- Specification rack system 2
- 3000w front end power system 3
- Block diagram 3
- Mechanical specification single unit 3
- Series 3
- 3000w front end power system 4
- Mechanical specification rack system 4
- Series 4
- 3000w front end power system 5
- Cn500 in out connector pins function description 5
- Cn500 pin no assignment 5
- Derating curve 5
- Series 5
- Static characteristics 5
- 3000w front end power system 6
- Function manual 6
- Series 6
- 3000w front end power system 7
- Address dip switch setting 7
- Addressing a0 a1 a2 7
- Front panel indicators corresponding signal at function pins 7
- I c bus interface option 7
- Rcp 1000 24 7
- Rcp 1000 48 7
- Series 7
- The dip switch down position is logic level 1 and the up position is level 0 address are applicable when modules rcp 1000 i c function are used 7
- 3000w front end power system 8
- A d scaling 8
- Analog function are provided by a single pcf8591 4 channel 8 bit a d converter when this device is read by the i c bus controller it provides an 8 bit 8
- Analog function read only 8
- Digital function are provided by a pcf8574 8 bit i o port device when this device is read by the i c bus controller a single 8 bit word provides the following information 8
- Digital function read only 8
- Eeprom function read only 8
- Eeprom slave address 8
- Pcf8574 slave address 8
- Pcf8591 control byte 8
- Pcf8591 slave address 8
- Series 8
- The eeprom is a 2048 bit 256 byte device which is preprogrammed at the factory with the following data 8
- The voltage reading is made inside the power supply unit before the oring diode and is typically 0 v higher than the actual output voltage the following table for the scaling should be employed 8
- Value byte value x resolution 8
- Word with the following information 8
