Gigabyte C621-SD8 (rev. 1.0) [21/46] S sata0 1 sata 6gb s connectors supported by the inte

29) S-SATA0~1 (SATA 6Gb/s Connectors, Supported by the Intel

PCH)

30) I-SATA0~7 (SATA 6Gb/s Connectors, Supported by the Intel

SCU)

31) BAT

S-SATA0

S-SATA1

I-SATA0

I-SATA1

I-SATA2

I-SATA3

I-SATA4

I-SATA5

I-SATA6

I-SATA7

- 21 -
