1-2 ProductSpecications
CPU 1st and 2nd Generation Intel
®
Xeon
®
Scalable Processors, Dual LGA 3647 Socket
P (Square) with 2 UPI support of up to 10.4 GT/s, CPU TDP support up to 165W
Chipset Intel
®
C621 Chipset
Memory 8 x DDR4 DIMM sockets supporting up to 1 TB of system memory
8 channel memory architecture (4 channel per CPU)
Support for DDR4 2666 MHz memory modules if use a Skylake CPU
Support for DDR4 2933 MHz memory modules if use a Cascade lake CPU
Support for ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS memory modules
Onboard
Graphics
ASPEED
®
AST2500:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
LAN 1 x Realtek RTL8211E chip (10/100/1000 Mbit) (LAN1)
2 x Intel
®
210AT GbE LAN chips (10/100/1000 Mbit) (LAN2, LAN3)
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_3, PCIEX16_5)
1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
2 x PCI Express x8 slots, running at x8 (PCIEX8_2, PCIEX8_6)
1 x PCI Express x8 slot, running at x4 (PCIEX4_4)
(All of the PCI Express x16 slots conform to PCI Express 3.0 standard.)
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe x4/x2 SSD support)
- 8 x SATA 6Gb/s connectors (I-SATA0~I-SATA7)
- 2 x SATA 6Gb/s connectors (S-SATA0, S-SATA1)
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
USB Chipset:
- 5 x USB 3.1 Gen 1 ports (2 ports on the back panel, 1 port onboard, 2 ports
available through the internal USB header)
- 2 x USB 2.0/1.1 ports available through the internal USB header
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x CPU fan headers
6 x system fan headers
1 x M.2 Socket 3 connector
10 x SATA 6Gb/s connectors
2 x SATA DOM power headers
1 x PMBus connector
1 x Intel
®
VROC Upgrade Key header
1 x front panel header
1 x USB 3.1 Gen 1 header
1 x USB 3.1 Gen 1 port
1 x USB 2.0/1.1 header
1 x Trusted Platform Module (TPM) header
1 x serial port connector
1 x chassis intrusion header
3 x SATA SGPIO headers
1 x SMD_VMD header
- 8 -
