41 IPMB IPMB connectot
42 COM2 Serial port cable connector
43 RAID_SLOT1 PCI Express x8 slot
44 PCIE_1 PCI Express x1 slot
45 BIOS_PWD Clearing Supervisor Password jumper
46 MINI_CN1 Mini-SAS cable connector#1 supports SATA3 6Gb/s
47 MINI_CN2 Mini-SAS cable connector#2 supports SATA3 6Gb/s
48 BMC_FRB Force to Stop FRB Timer jumper
49 PCIE_2 PCI Express x4 slot
50 BIOS_RVCR BIOS recovery jumper
51 LED_BMC BMCrmwarereadinessLED
52 PCIE_3 PCI Express x8 slot
53 S3_MASK S3 Power On Select jumper
54 PCIE_4 PCI Express x8 slot
55 PCIE_5 PCI Express x8 slot
56 DIMM_P1_F0 Channel 2 slot (for secondary CPU)
57 DIMM_P1_E0 Channel 1 slot (for secondary CPU)
58 CLR_CMOS Clear CMOS jumper
59 BAT Battery socket
CAUTION! If a SATA type hard drive is connected to the motherboard, please ensure the jumper is
closed and set to 2-3 pins (Default setting), in order to reduce any risk of hard disk damage. Please
refer to Page 32 for SATA_DOM0 jumper setting instruction.
