Hardware Installation - 12 -
1-2 Product Specications
System fan
Dimensions 5U
447mm (W) x 219.6mm (H) x 900mm (D)
System fan
CPU 2nd Generation Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon®Gold Processor, Intel® Xeon®
Silver Processor and Intel® Xeon® Bronze Processor
NOTE! If only 1 CPU is installed, some PCIe and memory functions might be
unavailable.
System fan
Socket 2 x LGA 3647
Socket P
System TDP up to 205W
System fan
Chipset
Intel® C621 Express Chipset
System fan
Memory 24 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
1.2V modules: 2933( 1DPC)/2666/2400 MHz
System fan
LAN 2 x 1Gb/s BASE-T LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
System fan
Expansion Slot 32 x PCIe x16 low prole half-lengh slots (Gen3 x16 bus) for GPUs
8 x PCIe x16 low prole half-lengh slots (Gen3 x16 bus) for LAN connectivity
1 x PCIe low prole half-lengh slots (Gen3 x8 bus) for add-on cards ( Front side)
1 x OCP 2.0 mezzanine slot ( Rear side)
- PCIe Gen3 x8
- Type1, P1, P2, P3, P4, K2, K3
System fan
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
System fan
Storage 4 x 2.5" NVMe, 6 x 2.5" SATA/SAS hot-swappable HDD/SSD bays
SAS card is required to enable SAS devices support
System fan
Internal I/O 1 x TPM header
1 x VROC connector
1 x Front VGA header
1 x Serial header
