Gigabyte G591-HS0 (rev. 100) [51/113] 2 1 trusted computing

- 51 - BIOS Setup

5-2-1 Trusted Computing

Parameter

Description

Conguration

Security Device Support

Enable/Disable the TPM support feature.

Options available: Enable/Disable. Default setting is Enable.

Current Status Information

Displays current TPM status information.
