Hardware Installation - 11 -

1-2 Product Specications

Socket

CPU  Intel® Core™ X series 44-lane/28-lane processors

Socket

Socket  1 x LGA 2066

 Mounting pitch: square ILM (80x80mm)

Socket

Chipset

 Intel® X299 Express Chipset

Socket

Memory  8 x DIMM slots

 DDR4 memory modules supported only

 Quad channel memory architecture

 Support for non-ECC Un-buffered DIMM

 DDR4 modules: 2667/2400/2133 MHz

Socket

LAN  2 x 1Gb/s LAN ports (Intel® I350-AM2)

 1 x 10/100/1000 management LAN

Socket

Expansion Slot  1 x PCIe x16 slots (Gen3 x16), Low prole half-length*

 * The PCIe slot is unavailable for system level

 * The PCIe slot is shared with riser card 1 x PCIe x16 signal

Riser Card CRS1027:

 - 1 x PCIe x16 slots (Gen3 x16), Low prole half-length

2 x M.2 slots:

 - M-key

 - PCIe Gen3 x4

 - Supports NGFF-2242/2260/2280 cards

Socket

Video  Integrated in Aspeed® AST2500

 2D Video Graphic Adapter with PCIe bus interface

 1920x1200@60Hz 32bpp, DDR4 SDRAM

Socket

Storage  2 x U.2, 4 x SATA/SAS or 6 x SATA/SAS hot-swappable HDD/SSD bays

 2.5" HDD supported only

Socket

SATA  Supported

Socket

SAS  Supported via add-on SAS Card
