Hardware Installation - 12 -

1-2 Product Specications

CPU  2ndGenerationIntel®Xeon®ScalableandIntel®Xeon®ScalableProcessors

 Intel®Xeon®PlatinumProcessor,Intel®Xeon®GoldProcessor,Intel®Xeon®

SilverProcessorandIntel®Xeon®BronzeProcessor

NOTE:Ifonly1CPUisinstalled,somePCIeormemoryfunctionsmightbe

unavailable.

Socket  2xLGA3647

 SocketP0

 Mountingpitch:NarrowILM

Chipset

 Intel®C621ExpressChipset

Memory  24xDIMMslots

 DDR4memorysupportedonly

 6-channelmemoryarchitecture

 RDIMMmodulesupto32GBsupported

 LRDIMMmodulesupto64GBsupported

 SupportIntel®Optane™DCPersistentMemory

 1.2Vmodules:2933(1DPC)/2666/2400/2133MHz

NOTE:

1. 2933MHzfor2ndGenerationIntel®Xeon®ScalableProcessorsonly

2. Intel®Optane™DCPersistentMemoryfor2ndGenerationIntel®Xeon®

Scalable Processors only

LAN  2x1Gb/sLANports(Intel®I350-AM2)

 1x10/100/1000managementLAN

Expansion Slot

(R181-2A0)

(R181-N20)

 RiserCardCRS1021:

 -2xPCIex8slots(Gen3x8),Lowprolehalf-length

 RiserCardCRS1015:

 -1xPCIex16slot(Gen3x16),Lowprolehalf-length

 2xOCPmezzanineslots

 -PCIeGen3x16

 -Type1,P1,P2,P3,P4,K2,K3

(R181-NA0)  RiserCardCRS1014:

 -1xPCIex16slot(Gen3x16),Full-heighthalf-length

 RiserCardCRS1015:

 -1xPCIex16slot(Gen3x16),Full-heighthalf-length

 -OccupiedbyCNV3124,4xU.2HBA

 2xOCPmezzanineslots

 -PCIeGen3x16

 -Type1,P1,P2,P3,P4,K2,K3

 -1xOCPmezzanineslotisOccupiedbyCNVO124,4xU.2mezzaninecard
