- 31 - System Hardware Installation

3-5 Installing the PCI Expansion Card

• VoltagescanbepresentwithintheserverwheneveranAC power source is connected.This

voltage is present even when the main power switch is in the off position. Ensure that the

system is powered-down and all power sources have been disconnected from the server prior to

installingaPCIcard.

Failure to observe these warnings could result in personal injury or damage to equipment.

• ThePCIriserassemblydoesnotincludearisercardoranycablingasstandard.ToinstallaPCI

card,arisercardmustbeinstalled.

Follow these instructions to PCI Expansion card:

1. Remove the securing special screw on the riser bracket.

2. Remove the thumbscrew on the riser bracket

3. Liftuptheriserbracketoutofsystem.

4. Remove the slot covers from the riser bracket.

5. OrientthePCI-EcardwiththeriserguideslotandpushinthedirectionofthearrowuntilthePCI-E

cardsitsinthePCIcardconnector.

6. SecurethePCI-Ecardwiththescrew.

7. Reverse the steps 3 - 1 to install the riser bracket.

Available on Selected Models

PCIe x8

R181-2A0/R181-N20
