- 19 - System Appearance
2-3 Front Panel LED and Buttons
L1 L2
2
4
6
8
1
3
5
7
No. Name Color Status Description
1.
Reset Button Pressthebuttontoresetthesystem.
2.
NMIbutton
PressthebuttonservergeneratesaNMItotheprocessor
ifthemultiple-bitECCerrorsoccur,whicheffectivelyhalt
theserver.
3.
Powerbutton
withLED
Green On Systemispoweredon
Green Blink SystemisinACPIS1state(sleepmode)
N/A Off
• SystemisnotpoweredonorinACPIS5state
(poweroff)
• SystemisinACPIS4state(hibernatemode)
4.
IDButton Pressthebuttontoactivatesystemidentication
5.
HDD Status
LED
Green
On HDD locate
Blink HDD access
Amber On HDD fault
Green/
Amber
Blink HDD rebuilding
N/A Off NoHDDaccessornoHDDfault.
6.
System
Status LED
Green Solid On Systemisoperatingnormally.
Amber
Solid On
Criticalcondition,mayindicate:
Systemfanfailure
Systemtemperature
Blink
Non-criticalcondition,mayindicate:
Redundantpowermodulefailure
Temperature and voltage issue
Chassisintrusion
N/A Off
Systemisnotready,mayindicate:
POST error
NMIerror
Processor or terminator missing
7/8.
LAN1/2
Active/Link
LEDs
Green Solid On Linkbetweensystemandnetworkornoaccess.
Green Blink Data trasmission or receiving is occuring
N/A Off Nodatatransmissionorreceivingisoccuring
