BIOS Setup - 102 -
Parameter Description
PCIe UnCorr GHES Notify
Type
Notication type for PCIe uncorrected errors.
Options Available: Polled/NMI. Default option is NMI.
PCIe Root Port Corr Err Mask
Reg
Enter a value.
Intialize the PCIe AER Corrected Error Mask register of Root Port.
PCIe Root Port UnCorr Err
Mask Reg
Enter a value.
Intialize the PCIe AER Uncorrected Error Mask register of Root Port.
PCIe Root Port UnCorr Error
Sev Reg
Enter a value.
Intialize the PCIe AER Uncorrected Error Severity register of Root Port.
PCIe Device Corr Err Mask
Reg
Enter a value.
Intialize the PCIe AER Corrected Error Mask register of PCIe Device.
PCIe Device UnCorr Err Mask
Reg
Enter a value.
Intialize the PCIe AER Uncorrected Error Mask register of PCIe Device.
PCIe Device UnCorr Error Sev
Reg
Enter a value.
Intialize the PCIe AER Uncorrected Error Severity registers of PCIe
Device.
CCIX GHES Deferred Err
Notify Type
Notication type for CCIX deferred errors.
Options Available: Polled/SCI. Default option is Polled.
CCIX GHES Corrected Err
Notify Type
Notication type for CCIX corrected errors.
Options Available: Polled/SCI. Default option is Polled.
DDR4 DRAM Hard Post
Package Repair
This feature allows spare DRAM rows to replace malfunctioning rows via
an in-eld repair mechanism.
Options Available: Disabled/Enabled. Default option is Disabled.
HEST DMC Structure Support
HEST DMC (Deferred Machine Check) Structure Support.
Options Available: Disabled/Enabled. Default option is Disabled.
