Gigabyte G492-Z51 (rev. 100) [103/141] 5 chipset setup menu

- 103 - BIOS Setup

5-5 Chipset Setup Menu

Chipset Setup menu displays submenu options for conguring the function of the North Bridge. Select a

submenu item, then press [Enter] to access the related submenu screen.

Parameter Description

PCIe Link Training Type

PCIe Link training in 1 or 2 steps.

Options available: 1 Step/2Step. Default setting is 1 Step.

PCIe Compliance Mode Options available: On/Off. Default setting is Off.

Program All VR

Enables or disables program all VR on MB.

Options available: Disabled/Enabled. Default setting is Enabled.

North Bridge Press [Enter] for more information related to CPU 0 and CPU 1.
