Gigabyte G492-Z51 (rev. 100) [20/141] 4 front system lan leds

- 20 - System Appearance

2-4 Front System LAN LEDs

1 1

2 2

No. Name Color Status Description

GbE Speed

LED

Yellow On 1 Gbps data rate

Green On 100 Mbps data rate

N/A Off 10 Mbps data rate

GbE Link /

Activity LED

Green

On Link between system and network or no access

Blink Data transmission or reception is occurring.

N/A Off No data transmission or reception is occurring.
