- 13 - Hardware Installation
(G492-Z51) 10 x PCIe x16 slots (Gen4 x16 bus) for GPUs ( Broadcom solution)
2 x PCIe x16 (Gen4 x16 bus) Half-length low-prole slot in front side
1 x PCIe x16 (Gen4 x16 bus) Half-length low-prole slot in rear side#
# Non-supported SAS Card with internal cable due to cable routing limitation
8 x PCIe x16 slots (Gen4 x16 bus) for GPU
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 in rear side
- System is validated for population with a uniform GPU model
- Support is not provided for mixed GPU populations
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage 12 x 3.5" hot-swappable HDD/SSD bays
- 8 x amber HDD trays compatible with NVMe or SATA/SAS devices
- 4 x blue HDD trays compatible with SATA/SAS devices only
SAS card is required for SAS devices support
SAS/SATA SAS Supported
SATA Supported
Internal I/O 1 x TPM header
1 x Front panel header
Front I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD access LED
Backplane I/O 12 x 3.5" ports
Speed and bandwidth: PCIe Gen3 or SAS 12Gb/s or SATA 6Gb/s
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
