GSM Server - 34 -

3-3-4 NetworkConguraiton

This page provides GroupIPv4andIPv6DHCPconguration.

Parameter

Decription/Resulting Action

IPv4 setting

IPv6 Setting

Use DHCP

Click on tab to enable or disable this function

IP Address

Identify the IP address.

Subnet Mask

ConguretheSubnetMaskaddress.

Gateway

DenetheGatewayaddress

Whenyounishtheconguration,clkickSubmittosaveyourconguration.
