BIOS Setup - 110 -

5-5 Chipset Setup Menu

Chipset Setup menu displays submenu options for conguring the function of the Soc. Select a submenu

item, then press [Enter] to access the related submenu screen.

Parameter Description

PCIe Link Training Type

PCIe Link training in 1 or 2 steps.

Options available: 1 Step/2Step. Default setting is 1 Step.

PCIe Compliance Mode Options available: On/Off. Default setting is Off.

Program All VR

Enable/Disable program all VR on MB.

Options available: Enabled/Disabled. Default setting is Enabled.

North Bridge Press [Enter] for conguration of advanced items.
