- 2 -
Copyright
© 2019 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior
notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any
form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
User Manual: detailed information & steps about the installation, conguration and use this
product (motherboard), covering hardware & BIOS
Service Guide: detailed information & steps about the installation, conguration and use of
this product (server barebones), covering hardware & BIOS
User Guide: information about a particular rmware or software package that can be used
with this product (such as BMC rmware)
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes
Please see the support section of the online product page to check the current availability of these docu-
ments
For More Information
For related product specications, the latest rmware and software, and related information, please visit our
website at:
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our re-
seller portal:
http://reseller.b2b.gigabyte.com
