Hardware Installation - 12 -
1-2 Product Specications
CPU AMD EPYC™ 7002 series processor family
Dual processors, 7nm technology
Up to 64-core, 128 threads
TDP up to 225W*
NOTE:
1. H262-Z61: Supports TDP up to 200W
2. H262-Z62: Supports TDP up to 200W
3. H262-Z63: Supports TDP up to 225W
4. H262-Z66: Supports TDP up to 200W
5. If only 1 CPU is installed, some PCIe or memory functions might be
6. Contact GIGABYTE sales rep or technical support for more details about
supporting cTDP 240W CPU
Compatible with AMD EPYC™ 7001 series processor family
Socket
Per Node:
2 x LGA 4094
Total:
8 x LGA 4094
Socket SP3
Chipset System on Chip (SoC)
Memory Per Node:
16 x DIMM slots
Total:
64 x DIMM slots
DDR4 memory supported only
8-Channel memory per processor architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200 MHz
LAN Per Node:
2 x 1GbE LAN ports (1 x Intel® I350-AM2)
1 x Dedicated management port
Total:
8 x 1GbE LAN ports (1 x Intel® I350-AM2)
4 x Dedicated management ports
1 x 10/100/1000 *CMC global management port
*CMC: Chassis Management Controller, to monitor all status of computing nodes
