- 13 - Hardware Installation
Expansion Slots Per node:
2 x Low prole half-length slots with PCIe x16 (Gen4 x16 bus) from CPU_0
1 x OCP 2.0 mezzanine slot with PCIe Gen3 x16 bandwidth from CPU_0 (Type1,
P1, P2, P3, P4 with NCSI supported)
2 x M.2 slots from CPU_0 and CPU_1:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280/22110 cards
Total:
8 x Low prole half-length slots with PCIe x16 (Gen4 x16 bus) from CPU_0
4 x OCP 2.0 mezzanine slots with PCIe Gen3 x16 bandwidth from CPU_0 (Type1,
P1, P2, P3, P4 with NCSI supported)
8 x M.2 slots from CPU_0 and CPU_1:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280/22110 cards
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage
(H262-Z61)
Per node:
6 x 2.5" SAS/SATA hot-swappable HDD/SSD bays
Total:
24 x 2.5" hot-swappable HDD/SSD bays
SAS card is required for SAS devices support
(H262-Z62) Per node:
6 x 2.5" NVMe hot-swappable SSD bays
Total:
24 x 2.5" NVMe hot-swappable SSD bays
All storage bays are compatible with SATA devices
(H262-Z63) Per node:
2 x 2.5" NVMe hot-swappable SSD bays
Total:
8 x 2.5" NVMe hot-swappable SSD bays
All storage bays are compatible with SATA devices
