Solar System
High Frequency Solar Inverter
-01- -02-
PV1100 Series
High Frequency Solar Inverter
Power Rate(w)
backup time(H)
@1*100Ah
backup time(H)
@2*100Ah
backup time(H)
@4*100Ah
backup time(H)
@4*200Ah
700
800
1440
1.6
1.3
3.2
2.6
1.4
6.4
5.2
12.8
10.4
2.8 5.6
Approximate Back-up Time Table
Feature:
Introduction:
Back Panel
Solar System Connection
Modified sine wave AC output, wide application range;
Charge current 15/20A adjustable, for model 700W/800W
Inbuilt with 30A or 50A solar charge controller
Three-steps intelligent charging control
Battery reverse protection function
Compact size fit for home use, small solar system
PV11-1200 PV11-1400
1200VA/700W 1400VA/800W
Narrow
Wide
3.5 3.5
2400VA/1440W
Rated Power
Output Voltage Regulation
+10/-18%
MODEL
PV11-2400
Default Battery System Voltage
12VDC 24VDC
Modifided Sine-wave
Voltage
230VAC
Output Frequency
50Hz/60Hz +/-1 Hz
Nominal Output Voltage RMS
Inverter Efficiency(Peak)
>80%
Line Mode Efficiency
>95%
INVERTER
OUTPUT
230V
Typical Transfer Time
Typical 15~20ms 40ms max
Waveform
Selectable Voltage Range
170~280VAC
90~280VAC
AC
INPUT
Frequency Range 50HZ/60HZ (Auto sensing)
BATTERY
Nominal Input Voltage
12VDC 24VDC
Minimum Start Voltage
10.5VDC 21.0VDC
Low Battery Alarm
10.5VDC+/-0.4V 21.0VDC+/-0.8V
Low Battery Cutoff
10.0VDC+/-0.4V 20.0VDC+/-0.8V
High Voltage Cutoff
15.0VDC+/-0.4V 30.0VDC+/-0.8V
MECHANICAL
SPECIFICATIONS
Dimensions (W*H*D)
268*260*90mm
Net Weight (kg)
3.5
OTHER
Operation Temperature Range
0°C to 50°C
Audible Noise
50dB MAX
Display
LED+LCD
Loading(20GP/40GP/40HQ) 1700pcs / 3400pcs / 4100pcs
AC Charger Voltage (Vbat<12.5V) 14.4VDC+/-0.2V 28.8VDC+/-0.4V
AC Charger Voltage (Vbat>12.5V) 13.7VDC+/-0.2V 27.4VDC+/-0.4V
AC Charging Current
Maximum Charge Current
BYPASS
&
PROTECTION
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load)
FUSE
Output Short Circuit Protection
FUSE
Bypass Fuse Rating
10A
15A/20A±2A @ PV Charger 0-10A
8A @ PV Charger 10A-20A
No Charging @ PV Charger 20A-30A
30A or 50A
10A±2A @ PV Charger 0-10A
3A @ PV Charger 10A-20A
No Charging @ PV Charger 20A-30A
10Amp
Max Bypass Current
SOLAR
CHARGER
&
AC CHARGER
Maximum PV Array Open Circuit Voltage
Maximum Efficiency
30A or 50A
12V/24V atuo work
55VDC
>95%
<2W
450W/750W
Standby Power Consumption
900W/1500W
Maximum PV Charge Current
DC Voltage
Maximum PV Array Power
PWM Range @ Operating Voltage
16~55VDC
1. DC Input Wires
2. Input fuse
3. AC Input Connector(Three-station Terminal Block)
4. Output Receptacle(s)
5. For 660W/800W,Switch 15A/20A
6. Input Voltage Range Selector
Note: Do not reverse the polarities
7. PV input,note that the polarity is not reversed.
8. AC/PV charging priority.
1. LED
2. LCD
3. POWER ON/OFF
Figure 1 Top Panel
Figure 2 Back Panel
156
7
2
3 8
4
It is a cost effective & intelligent solar inverter, accepting Solar & Utilities input at the same time,with DC/AC priority configurable .
In condition of DC priority ,When battery voltage is low,it will automatically switch to AC & continously offer power to the loads.
LCD Display Information
External
Battery pack
PV panel
3
1 2
+
-
OUTPUT LOAD
LINE MODE
BACKUP MODE
WATT
VA
OUTP UT VO LT FAU LT
VOLT
PV+
PV-
OUTPUT
NARROW
WIDE
15A
CH ARG E
20A
+ Battery -
INPUT
Charge Priority
AC
PV
Utility
Home Appliances
