Solar System
Hybrid Inverter
-05- -06-
PH2000 ES Series
Hybrid Inverter
Feature:
Specification
Li-ion /Lead-acid battery
Operation:On-Grid(5kW),Charging and discharging(2.5kW),
Backup(2.3kW)
Zero export to grid
U-disk for software updating
Without LCD,no risk of dust or water
Seperate APP setting/monitoring
Wi-Fi/GPRS
Lantrun Pad local monitoring
Input Data (DC)
Max. DC power
Max. DC voltage
Start voltage
DC nominal voltage
PV voltage range
MPP voltage range
Max. input current per string of tracker A/tracker B
Number of independent MPP inputs
Output Data (AC)
Nominal AC output power
Max. AC apparent power
Max. output current
AC nominal voltage; range
AC grid frequency; range
Power factor at rate power
Power factor
THDi
AC connection
Battery
Battery type
Norminal voltage
Battery capacity
Energy
Max. discharging /charging power
Charging curve
Operating voltage range
Max. charging/discharging current
Backup Output
Output rate power
Peak power
Output voltage
Euro - eta
Protection Devices
DC reverse polarity protection
DC switch rating for each MPPT
Output over current protection
Output overvoltage protection-varistor
Ground fault monitoring
Grid monitoring
Integrated all - pole sensitive leakage current
monitoring unit
General Data
Dimensions (W / H / D)
Weight
Operating temperature range
Noise emission (typical)
Altitude
Relative humidity
Consumption: operating (standby) / night
Topology
Cooling concept
Environmental Protection Rating
Features
DC connection
AC connection
Display
Interfaces: Wi-Fi/USB/GPRS/RS485
Warranty: 5 years / 10 years/15 years
3800W
3600W
3600VA
16.4 A
97.00%
96.50%
99.50%
24kg 24kg 24kg
97.10%
96.50%
99.50%
97.10%
96.50%
99.50%
5000W
600V
100V
360V
100V-600V
120V-550V
11A/11A
2
4600W
4600VA
21.0A
5400W
5000W
5000VA
22.8A
220V/230V/240V; 180V-280V
50,60Hz;±5 Hz
1
0.8leading…0.8lagging
<3%
Single phase
Lead-acid or Li-ion
48V
>=100Ah(depending requirement)
4.88kWh
2500W / 2500W
3-stage adaptive with maintenance
46V-57V
50A / 50A
2300VA
3450VA,10s
230V±2%, 50Hz (60Hz Optional)±0.2%, THDv<3%(linear load)
Yes
Yes
Yes
Yes
Yes
Yes
495/420/165mm
-25...+60°C (-13...+ 140°F) With derating above 45°C（113°F）
≤ 25 dB(A)
Up to 2000m (6560ft) Without power derating
95%
<5W / < 0.5 W
Transformerless
Natural
IP65
H4/MC4
Screw terminal
LED
Yes/Yes/Opt/Opt
Yes /Opt/Opt
CE,IEC 62109-1&2, VDE 0126-1-1,G83/2, AS4777&AS/NZS 3100
PH20-3600ES
Model
PH20-4600ES PH20-5000ES
Yes
Specifications
Efficiency
Max. efficiency
MPPT efficiency
Certificates and approvals
The unit is bidirectional which apply to PV system withbattery to store energy. Energy produced by the PV system is used to
optimize self-consumption; excess energy is used to charge the batteries, and then fed into the public grid when the PV energy
is adequate, When PV energy output is in sufficient to support connected loads, the system automatically get energy from the
batteries if battery capacity is abundant. If the battery capacity is insufficient to meet own consumption requirements, electricity
will be drawn from the public grid.
Introduction:
LCD Display Information
1. The inverter power flow direction indicator
2. The inverter operation status indicator
3. PV input terminals
4. Battery input terminals and cover
5. PV input switch
6. WIFI com module and USB port
7. BAT._NTC and RS485 communication (BMS com, load monitor com, )
8. AC Output terminals and cover
9. Inverter Serial No.
10. Spec label
11. Warning signals label
1
2
3 4 5 6 7 8
9
10
11
Solar System Connection
External
Battery pack
PV panel
Home Appliances
Utility
Back Panel
