tc
‧ : Max. Case Temperature
tc
※ AB-Type (for 12V model)
233
244
220
300±20
300±20
37.5
37
ACL(Brown)
ACN(Blue)
90
32
53.8
71
4-ψ4.5
SJOW 17AWGx2C
2
&H05RN-F 1.0mm
SJTW 14AWGx2C
Vo+(Red)
Vo-(Black)
tc
‧ : Max. Case Temperature
tc
※ AB-Type (for other models)
233
244
220
300±20
300±20
37.5
37
ACL(Brown)
ACN(Blue)
90
32
DIM-( )White
DIM+( )Blue
53.8
71
4-ψ4.5
SJOW 17AWGx2C
2
&H05RN-F 1.0mm
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
2
&05RN-F 1.0mm
UL2517 20AWGx2C
DIM-( )White
DIM+( )Blue
UL2517 20AWGx2C
38.5
21.01
14.5
38.5
21.01
14.5
144~200W Constant Voltage + Constant Current LED Driver
ELG-200 series
File Name:ELG-200-SPEC 2020-09-25
