![MEAN WELL ELG-200-42AB-3Y [3/13] Elg 200](/img/pdf.png)
MEAN WELL ELG-200-42AB-3Y [3/13] Elg 200
![MEAN WELL ELG-200-42AB-3Y [3/13] Elg 200](/views2/1685395/page3/bg3.png)
Block Diagram
PFC fosc : 50~120KHz
PWM fosc : 60~130KHz
144~200W Constant Voltage + Constant Current LED Driver
※ This series is able to work in either Constant Current mode (a direct drive way) or
Constant Voltage mode (usually through additional DC/DC driver) to drive the LEDs.
DRIVING METHODS OF LED MODULE
Typical output current normalized by rated current (%)
In the constant current region, the highest voltage at the output of the driver
depends on the configuration of the end systems.
Should there be any compatibility issues, please contact MEAN WELL.
100
50
(min.)
Vo(%)
50
100
Io(%)
(B)
Constant
Current area
(C)
Hiccup
Protection
(A)
Constant
Voltage area
DETECTION
PWM & PFC
CIRCUIT
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
Vo+
Vo-
I/P
CONTROL
O.V.P.
&
O.L.P.
PFC
CIRCUIT
O.L.P.O.T.P.O.T.P.
PFC CONTROL
ELG-200 series
CASE :Protective Earth
File Name:ELG-200-SPEC 2020-09-25
