ASRock X99 Extreme6/3.1 [79/102] Advanced screen
![ASRock X99 Extreme6/3.1 [79/102] Advanced screen](/views2/1686114/page79/bg4f.png)
73
English
X99 Extreme6/3.1
4.4 Advanced Screen
In this section, you may set the congurations for the following items: CPU Con-
guration, Chipset Conguration, Storage Conguration, Super IO Conguration,
ACPI Conguration, USB Conguration and Trusted Computing.
Setting wrong values in this section may cause the system to malfunction.
