ASRock X79 Extreme6/GB / X79 Extreme6 Motherboard
簡體中文
18、 EuP, 全稱 Energy Using Product( 能耗產品 ), 是歐盟用來定義完整系統
耗電量的規定。根據 E u P 的規定 , 一個完整系統在關機模式下的交流電總
消耗必須在 1.00W 以下。為滿足 EuP 標準 , 您需要同時具備支持 E uP 的主
板和支持 EuP 的電源供應器。根據 Intel
®
的建議 , 支持 EuP 的電源供應器
必須滿足在 100m A 電流消耗時 ,5V sb 電源效率高于 50%。有關支持 EuP 的
電源供應器選擇方面的更多細節 , 我們建議您諮詢電源供應器的製作商。
