繁體中文
Fatal1ty Z97 Professional Series
• Pixel Shader 5.0，DirectX 11.1
• 最大共用記憶體 1792MB
• 雙圖形輸出：透過獨立顯示控制器支援 HDMI 及
DisplayPort 1.2 連接埠
• 支援最高可達 4K x 2K (4096x2304) @ 24Hz 解析度的
HDMI
• 支援 DisplayPort 1.2，最高解析度可達 4K x 2K (4096x2304)
@ 24Hz 或 4K x 2K (3840x2160) @ 60Hz
• 支援使用 HDMI 連接埠（需相容於 HDMI 監視器）的
Auto Lip Sync、Deep Color (12bpc)、xvYCC 及 HBR（高位
元率音訊）
• 支援含 HDMI 及 DisplayPort 1.2 連接埠的 HDCP
• 支援透過 HDMI 及 DisplayPort 1.2 連接埠播放 Full HD
1080p Blu-ray (BD)
音訊
• 7.1 聲道 HD 音訊
• 支援防突波（華擎全防護）
• Nichicon Fine Gold 系列音效專用電容
• Creative Sound Core3D 四核心聲音與語音處理器
• 支援 SBX Pro Studio
• 支援 CrystalVoice
• 支援 Scout Mode
• 支援 EAX1.0 至 EAX5.0
• Premium Headset Amplier (PHA)
LAN
• 1 x Intel® I218V (Gigabit LAN PHY 10/100/1000 Mb/s)
• 1 x Qualcomm® Atheros® Killer
TM
E2200 系列 (PCIE x1
Gigabit LAN 10/100/1000 Mb/s)
• 支援 Intel® 遠端喚醒技術（以 Intel® I218V)
• 支援 Qualcomm® Atheros® Security Wake On Internet
Technology ( 使用 Qualcomm® Atheros® Killer
TM
E2200 系列 )
• 支援網路喚醒
• 支援防雷擊 / 防 ESD 靜電（華擎全防護）
• 支援 Energy Ecient Ethernet 802.3az
• 支援 PXE
