English
Fatal1ty Z97 Professional Series
Chapter 1 Introduction
ank you for purchasing ASRock Fatal1ty Z97 Professional Series motherboard,
a reliable motherboard produced under ASRock’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to
ASRock’s commitment to quality and endurance.
1.1 Package Contents
•
ASRock Fatal1ty Z97 Professional Series Motherboard (ATX Form Factor)
•
ASRock Fatal1ty Z97 Professional Series Quick Installation Guide
•
ASRock Fatal1ty Z97 Professional Series Support CD
•
4 x Serial ATA (SATA) Data Cables (Optional)
•
1 x I/O Panel Shield
•
1 x ASRock SLI_Bridge_2S Card
•
1 x HDD Saver Cable
•
1 x Screw for M.2_SSD (NGFF) Socket 3
•
1 x Screw for mini-PCIe Slot
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any modi-
cations of this documentation occur, the updated version will be available on ASRock’s
website without further notice. If you require technical support related to this mother-
board, please visit our website for specic information about the model you are using. You
may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com.
