41
ASRock XFast LAN UI Overview
The default status window
Right click for more options
Show/hide slot
activation area
Variance of
ping time
TX shaping
indicator
Open slot
conguration
dialog
Open Current
Connections window
Ping time in ms
Download CPS rate
Upload CPS rateGraphs Transfer rate
in % for slots 1-10
Upload activity display
Download activity display
Number of TCP/
UDP/TCP+UDP
connections
Low Latency Mode switch
arrow down = currently
on (if needed)
arrow up = always on
no arrow = off
