![ASRock G41MH/USB3 R2.0 [34/55] 3 4 3 4 3 4 3 4](/img/pdf.png)
ASRock G41MH/USB3 R2.0 [34/55] 3 4 3 4 3 4 3 4
![ASRock G41MH/USB3 R2.0 [34/55] 3 4 3 4 3 4 3 4](/views2/1689184/page34/bg22.png)
3434
3434
34
DRAM Voltage
Use this to select DRAM Voltage. The default value of this feature is [Auto].
NB Voltage
Use this to select NB Voltage. The default value of this feature is [Auto].
SB Voltage
Use this to select SB Voltage. The default value of this feature is [Auto].
VTT Voltage
Use this to select VTT Voltage. The default value of this feature is [Auto].
GLTREF Voltage
Use this to select GLTREF Voltage. The default value of this feature is
[Auto].
Would you like to save current setting user defaults?
In this option, you are allowed to load and save three user defaults
according to your own requirements.
